LPDDR
Samsung LPDDR4X
Proven 4266 Mbps low-power DRAM for automotive and mid-range mobile
Samsung · FBGA / PoP · Image: samsung.com
LPDDR4X at 4266 Mbps with automotive temperature grades, the volume choice for IVI, telematics, and mid-range devices.
- Interface
- LPDDR4X
- Form factor
- FBGA / PoP
- Capacities
- 2 GB4 GB6 GB8 GB
In the DRAM Components portfolio
LPDDR4X remains the volume low-power DRAM for automotive infotainment, telematics, mid-range smartphones, and connected consumer devices. Samsung supplies the part at 4266 Mbps in capacities to 8 GB, with a reduced 0.6 V I/O rail cutting interface power versus LPDDR4.
Automotive grades qualified to AEC-Q100 temperature ranges and long-term supply commitments make LPDDR4X a low-risk selection for vehicle programs with seven-plus-year production lives. The mature ecosystem of SoC support keeps integration effort minimal.
Verified specification
Figures as published by Samsung. Availability and firmware options are confirmed at quotation.
| Interface | LPDDR4X |
|---|---|
| Data Rate | Up to 4266 Mbps/pin |
| Package Capacities | 2 GB, 4 GB, 6 GB, 8 GB |
| I/O Voltage | 0.6 V VDDQ |
| Package | FBGA / PoP |
| Temp Grades | Consumer, industrial, automotive (-40°C to 105°C) |
| Qualification | AEC-Q100 grades available |
