MRDIMM
Micron MRDIMM DDR5 8800
Multiplexed-rank DIMM reaching 8800 MT/s effective bandwidth per module
Micron · MRDIMM
First-generation MRDIMM multiplexing two ranks to deliver 8800 MT/s to bandwidth-bound HPC and AI CPU workloads.
- Interface
- DDR5 MRDIMM
- Form factor
- MRDIMM
- Capacities
- 32 GB64 GB96 GB128 GB256 GB
In the DRAM Modules portfolio
The Micron MRDIMM multiplexes two DDR5 ranks through a data buffer so the host interface runs at an effective 8800 MT/s — roughly 40% more bandwidth than a 6400 MT/s RDIMM in the same slot. Capacities scale from 32 GB to 256 GB using standard and TSV-stacked packages.
MRDIMM targets CPU-bound HPC and AI workloads where cores starve on memory bandwidth: computational fluid dynamics, weather modeling, and inference on large language models running on host processors. The module is supported on Intel Xeon 6 P-core platforms with MRDIMM-enabled memory controllers.
Verified specification
Figures as published by Micron. Availability and firmware options are confirmed at quotation.
| Interface | DDR5 MRDIMM, 288-pin |
|---|---|
| Form Factor | MRDIMM |
| Capacities | 32 GB to 256 GB |
| Data Rate | 8800 MT/s effective |
| Organization | Dual-rank multiplexed, ECC |
| Voltage | 1.1 V |
| DRAM Type | Micron 1β DDR5 |
| Platform | Intel Xeon 6 (MRDIMM-enabled) |
